• High switching frequency for use in quick machine processes with high switching accuracy requirements.
• Display and flexible sensor settings for easy sensor handling and user-friendly operation.
• High gray line resolution enables the detection of very small contrast differences and high-gloss materials - high process stability and fewer downtimes.
• Various teach-in processes for ideal sensor and process setting in different applications.
• Manual switching threshold adjustment supports stable material detection and individual sensor adaption to different contrasts.

Technical data overview:

Dimensions:

(W x H x D) 26 mm x 62 mm x 47.5 mm

Sensing distance:

13 mm

Type of light:

LED White

LED RGB

Light spot size:

1.2 mm x 3.9 mm

Switching frequency:

12.5 kHz

25 kHz

Response time:

40 µs

20 µs

Switching output:

Push-pull: PNP/NPN

NPN

PNP, NPN

Adjustment:

2-point teach-in

Teach-in dynamic

2-point teach-in, teach-in dynamic

Connection type:

Male connector M12, 4-pin
